TRIPLE OFFSET BUTTERFLY VALVE, DOUBLE FLANGED RF, WCB/WCB/420SS/304SS+GRAPHITE, BARE STEM ,PN40 DN500 Product name   Three eccentric hard sealing flange butterfly valve Nominal diameter   DN 50-DN 3600 ( 2''- 144'') Nominal pressure   PN 6-PN 100  ( 86Lb - 600Lb ) Design standard   API 609 / EN593 (BS5155&DIN3354) Structure length   API 609 / EN558-1 [...]

Bellows Sealed Gate Valve， API 600， FLG 150 LB R.F. (125-250 Ra)， Cast ASTM A351 GR.CF8， 304SS Trim，Flanged ends, bolted bonnet, OS&Y, flexible wedge,integral seat ring, Hot oil system, steam system, hot and cold water system etc. Advantage 1.Bellow seal element. The key part of bellow sealed globe valves is mental bellow. It is the connection between cover and stem [...]

36”40”48”CONCENTRIC BUTTERFLY VALVE BUTTERFLY VALVE DOUBLE FLANGED ANSI 150, Concentric type BODY in DUCTILE IRON DISC in ALUBRONZE SHAFT in F51 Seat in BUNA-N Flanged ASME B 16.47 A FACE to FACE as in the table  MSS SP 67 Bare shaft Wafer Soft Seal Butterfly Valve uses the flexibility of rubber seat, could easily achieve zero leakge, therefore is a widely applied valve in oilfield, [...]

Triple offset butterfly valve double flanged, CF8/304SS, sealing ring:304ss+graphite, 150LB 6 "-24" Overview The Triple-eccentric design:shaft from the centerline of sealing surface to form the 1st eccentric;the shaft offsets from centerline of pipeline to form [...]

10K DN1200 Triple offset butterfly valve wafer type, body: CF8, disc: CF8, shaft: 17-4PH, sealing ring:304ss+graphite. Overview The Triple-eccentric design:shaft from the centerline of sealing surface to form the 1st eccentric;the shaft offsets from centerline of pipeline to form the 2nd eccentric;and the scalene cone form the 3rd [...]
